Kingston SSD|KINGSTON|DC600M|960 GB|1752xTBW rating|MTBF 2000000 h|Read speed 560 MB/s|Write speed 530 MB/s|Serial ATA III|2.5"|SEDC600M/960G

category code: SFM

cncode: 84717098

country of origin: China/Taiwan

data transfer rate: 6 Gbit/s

depth: 100.1 mm

Disclaimer: *Some of the listed capacity on a flash storage device is used for formatting and other functions and is thus not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products. For more information, go to Kingston’s Flash Guide at kingston.com/flashguide.
** Quality of service (QoS) of an SSD refers to the consistency and predictability of latency (response time) and IOPS (IOs per second) performance while servicing a read/write workload. QoS metrics demonstrate that, given a worst-case workload tested over a period of time, an SSD’s latency and IOPS profiles stay within a specified range without having unexpected outliers causing a sudden drop in application performance.
*** Measurement taken once the workload has reached a steady state but including all background activities required for normal operation and data reliability.
**** Based on 1.92TB capacity.
*****Workload based on FIO, random aligned 4KB QD=1 workload. Quality of service is measured as the time taken for 99.999 percentile of commands to finish the round trip from host to drive and to host. Typical latency is measured as the time taken for 99.9 percentile of commands to finish the round trip from host to drive and to host.
****** Total bytes written (TBW) is derived from the JEDEC Enterprise Workload (JESD219A).

height: 7 mm

master (outer) case gross weight: 989.98 g

master (outer) case height: 69.85 mm

master (outer) case length: 203.2 mm

master (outer) case width: 135.89 mm

Mean time between failures (MTBF): 2000000 h

memory type: 3D TLC NAND

model: SEDC600M/960G

operating temperature (t-t): 0 - 70 °C

package depth: 9.14 mm

package height: 184.15 mm

package weight: 91.2 g

package width: 129.54 mm

Products per master (outer) case: 10 pc(s)

read speed: 560 MB/s

SSD form factor: 2.5"

ssd series: DC600M

storage temperature (t-t): -40 - 85 °C

summary: Kingston Technology 960G DC600M (Mixed-Use) 2.5” Enterprise SATA SSD. SSD capacity: 960 GB, SSD form factor: 2.5", Read speed: 560 MB/s, Write speed: 530 MB/s, Data transfer rate: 6 Gbit/s, Component for: Server/workstation

unit box height: 0.2

unit box length: 0.07

unit box width: 0.014

unit calculated volume: 0.000196 cubm

unit calculated weight: 0.095 kg

units per shipping box: 10

weight: 69 g

width: 69.85 mm

write speed: 530 MB/s
